- Steel Material
features
- Bevel and Miter Gears Develop Axial Thrust
- Adequate Bearing support Must be Provided
- Miter Gears must be run in sets of two or more gears with the same pitch, Pressure angle and number of teeth
- Spiral Bevel and Miter Gears have continuous pitch line contact and are smoother and quieter than straight tooth gears. Spiral Bevel and Miter gears must be run in sets of mating gears with opposite hand spiral.
- Browning Gears are rated in accordance with AGMA standards
| Hub Type | Type B |
| Face Width (in) | 0.35 |
| Number of Teeth/Threads | 14 |
| Length Through Bore (in) | 0.96875 |
| Material | Steel |
| Hub Diameter (in) | 0.8125 |
| Diametral Pitch | 14 |
| Bore (Min) (in) | 0.5 |
| Pitch Diameter (in) | 1 |
| Gear Construction | Plain |
| Bore (Max) (in) | 0.5 |
| Hub Projection (in) | 0.5625 |
| Bore Size (in) | 0.5 |
| Pressure Angle | 20 |
| Bushing Bore Size (in) | 0.5000 |
| Bore Type | Minimum Plain Bore |
| Mounting Distance | 1.625 |
| Weight | 0.1 LB |
| EAN or UPC | 662289104741 |
