60H18H

Single Strand Sprocket; 60 Chain Size; 18 Teeth; Requires H Split Taper Bushing

Item #100970779

Auto Replenish

each One-time purchase

Alternate Products

Browning H60H18

Single Strand Sprocket; 60 Chain Size; 18 Teeth; Requires H Split Taper Bushing

Item #100931956

each

Compare

Product Details

Hardened teeth on the smaller sprocket of a roller chain drive are recommended if the drive ratio is four to one or greater or if the smaller sprocket has 24 teeth or less and is running at a speed of over 600 rpm.

Tolerances meet or exceed ANSI standards
Manufactured of high carbon steel
Precise machining and processes ensure consistent finish and high quality
Chain rows are parallel and precisely spaced to increase longevity of sprocket and chain
Bores are concentric to pitch line, minimizing run out
Interchangeable with other manufacturers’ split-taper bushings

Specifications

Bushing Bore [Max]	1.5 in
Bore Size [Min]	0.375 in
Bore Size [Max]	1.5 in
No. of Teeth Rows Strands	1
Tooth Width	0.459 in
Pitch Diameter	4.3191 in
Bushing Series	H
Chain No.	60
Inch/Metric	Inch
Material Internal Use	Carbon Steel
Pitch Dia.	4.319 in
Chain Sprocket Pitch	0.75 in
Type	3
O.D.	4.703 in
Bushing Bore Size [Min]	0.375 in
No. of Teeth	18
Outside Dia.	4.703 in
Bushing Type	Split Taper
Sprocket Style	B
Hub Length	0.42 in
Hub Projection	0.42 in
Outside Dia. [Min]	4.703 in
Bushing Bore [Min]	0.375 in
Chain Pitch	0.750 in
Overall Length Less Threads	N/A
Overall Length	1.5 in
No. of Strands Across	1
Hub O.D.	2.5 in
Hardened Teeth	With Hardened Teeth
Hub Dia.	2 1/2 in
Caliper Diameter	3.8501 in
Material	Steel
Construction Internal	Solid
Chain Sprocket Number	60
Single Strand Tooth Thickness	0.459 in
Width Across Teeth	0.459 in
Bushing Bore Size [Max]	1.5 in
Length Through Bore	0.875 in
Bore Type	Bushed
Material External Use	Steel
Weight	1.81 LB
EAN or UPC	697950110820
