Reduced maintenance design with plug and includes Sealmaster® Tapered Lands ensures that lubricant will be easily redirected back to the raceway.
USDA H1 complaint food grade grease
High phosphorous electroless nickel plated 52100 steel for exceptional corrosion resistance
High performance triple lip contact seal design provides multi-directional sealing with 304 stainless steel body and flinger to minimize contamination ingress and retain lubrication
High quality solid base designed investment cast passivated 316 stainless steel casting providing the highest amount corrosion resistance currently available for stainless steel housings.
Solid construction with machined base was designed for minimal gaps and no fillers
Skwezloc® Concentric locking for near perfect concentricity with fluoropolymer coated collar and corrosion resistant cap screw
Exclusive locking pin and dimple system provides a direct lubricant into the bearing cavity & ball path instead of around a lubrication groove, prevents outer ring rotation.
Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
options
Corrosion Resistant - Reduced Maintenance - Lubed for Life
Locking Type
Concentric
Foot Height
0.563 in, 14.3 mm
Maximum Operating Temperature
220
Outer Ring Land Profile
Tapered
Overall Height to Inner Ring
2.157 in, 54.8 mm
Internal Clearance
Standard
Bolt Center-to-Center Length (mm)
157.2
Certifications
IP69K
Overall Height to Inner Ring (in)
2.157
Bolt Center-to-Center Length
157.2 mm
Radial Dynamic Load Capacity
7889 lb
Pilot Configuration
No Pilot
Backside Shield/Seal
Optional backside shield available order separate
Bolt Size
0.563 in
Bore Size - Metric
50
Series
CRFTS
Housing Base
Solid
Insert No.
PN-210T
Overall Length
188.9 mm
Expansion
No
Bore Shape
Straight
Platform
PN Gold
Angle of Misalignment
±2°
Seal Type
Triple Lip Contact
Foot Height (in)
0.563
Mounted Unit Duty
Standard Duty
Foot Height (mm)
14.3
Bolt Size (in)
0.5625
Inner Race Heat Treat Method
Zone-Hardened
Housing Color
Silver
Housing Length
7 7/16 in
Speed [Max]
1500 rpm
Insert Material
52100 Bearing Steel, Phosphorus Nickel Coated
Overall Height to Inner Ring (mm)
54.8
Relubricatable
No
Housing Material
Stainless Steel
Locking Device
Setscrew Locking Collar
End Type
Open End
Duty Series
Standard
Housing Construction
One Piece
Bolt Hole Spacing
6 3/16 in
Measure Units
Metric
Flange Type
2-Bolt Flange
Bolt Circle Dia.
6 3/16 in
Bearing Design
Non-Expansion
Lubrication
Calcium Sulfonate NLGI 2 NSF H1 Food Grade Grease
End Cap
Yes
Misalignment Type
Static Only
Replaceable Insert
Yes
Bore Size
50 mm
Bearing Type
Ball Bearing
Overall Length (mm)
188.9
Centerline to Front Face (in)
3.8
Inch/Metric
Metric
Shaft Dia.
50 mm
Centerline to Front Face (mm)
96.8
Retainer Type
Land Riding
Centerline to Front Face
3.8 in, 96.8 mm
Bearing Insert Coating
Phosphorus Nickel
Operating Temperature [Max]
220 °F
Special Features
Reduced Maintenance
Weight
6.7 LB
EAN or UPC
662461370773
