- ODP Enclosure
- 7 1/2 hp
- 60 Hz Frequency
- 184TC Frame
| Base | No Mounting |
| Conduit Box Material | Steel |
| Insulation Class | F |
| Poles | 2 |
| Ambient Temperature | 104 °F |
| Type | AC Motor |
| Shaft Dia. | 1.125 in |
| Frame Size | 184TC |
| Service Factor | 1.15 |
| Frame Material | Steel |
| Shaft Diameter | 1.13 in |
| Duty Cycle | Continuous |
| Frequency | 60 Hz |
| Efficiency | 88.5% |
| HP | 7 1/2 |
| NEMA Design | A |
| Synchronous | 3600 rpm |
| Phase | Three Phase |
| Speed | 3480 rpm |
| Shaft Rotation | Reversible |
| Full Load Current | 18.4-17.4/8.7 |
| End Plate | C-Face |
| Enclosure | ODP |
| Power Factor | 89 |
| Standard | CSA EEV, NEMA_PREMIUM, UR, NEMA |
| Shaft Grounding | No |
| Voltage | 230 V, 460 V |
| Rated Efficiency | 88.5 % |
| Multispeed | Single Speed |
| Mount Type | F1 |
| Overall Length | 16.54 in |
| Weight | 77.0 LB |
| EAN or UPC | 781568818152 |
