Wide Inner Ring Cast Iron Housing Material Pillow Block

UCP206-18

Wide Inner Ring Cast Iron Housing Material Pillow Block
Item #101506385
  • 1 1/8 in Shaft Diameter
  • 1 11/16 in Center Line To Base Dimension
  • 4 7/16 in Bolt Hole Spacing Range [MIN]
Wide Inner Ring Cast Iron Housing Material Pillow Block
Price Unavailable
Price Unavailable
Pricing is unavailable at this time. Please contact Customer Service for assistance.
Online Ordering Restricted
Please contact Customer Service for assistance.
Contact Customer Service
    Shipment Options
  • 1 1/8 in Shaft Diameter
  • 1 11/16 in Center Line To Base Dimension
  • 4 7/16 in Bolt Hole Spacing Range [MIN]
Housing Height 3 9/32 in
Bearing Type Ball Bearing
Inch/Metric Inch Bore
Bolt Hole Width 21/32 in
Housing Material Cast Iron
Housing Construction 1 Piece
Base Height 23/32 in
Lubrication Relubricatable
Insert Material AISI 52100 Steel
End Type Open End
Length Through Bore 1.500 in
Bolt Hole Spacing Range [Min] 4 7/16 in
Locking Device Setscrew Locking Collar
Mounted Unit Duty Normal-Duty
Bearing Insert UC206-18
Bolt Hole Length 13/16 in
Shaft Dia. 1.125 in
Housing P206T
Series UCP200
Bolt Size 1/2 in
Relubricatable Yes
Housing No. P206
Base Length 6 1/2 in
Pillow Block Type Thru-Bolt
Bearing Design Non-Expansion
Base Width 1 7/8 in
Bolt Hole Spacing 4 3/4 in
Duty Series Normal
Lubrication Fitting Tap 1/8-27 NPT
Bolt Holes 2
Seal Type Contact Seals
Bolt Hole Spacing Range [Max] 5 1/16 in
Locking Style Set Screw
Weight 3.28 LB
EAN or UPC 808250109128
