Double Rocking Dog D-Handle Impact Wrench

T019139

Double Rocking Dog D-Handle Impact Wrench
Item #103295648
  • 4200 rpm Free Speed
  • 3/8 in Air Inlet Thread Size
  • 1400 ft.lbf Maximum Torque Reverse
Double Rocking Dog D-Handle Impact Wrench
Price Unavailable
Price Unavailable
Pricing is unavailable at this time. Please contact Customer Service for assistance.
Online Ordering Restricted
Please contact Customer Service for assistance.
Contact Customer Service
    Shipment Options
  • 4200 rpm Free Speed
  • 3/8 in Air Inlet Thread Size
  • 1400 ft.lbf Maximum Torque Reverse

features

  • 1,400 Ft.lbs (1,898 Nm) Of Max Torque In Reverse Position For High Productivity
  • Metal Housing And Rocking Dog Impact Mechanism For High Durability And Smooth Operation
  • Convenient Reverse Valve And Teasing Trigger For Better Comfort In Use
Handle Type D-Handle
Blows/Minute 1080 bpm
Side Handle Yes
Dynamic Air Working Pressure [max] 90 psi, 6.3 bar
Output Drive Type Square
Atex No
Free Speed 4200 rpm
Hose Diameter [min] (5 M Hose Length) 13 mm
Working Torque Forward [Min] 150 ft.lbf, 203 Nm
Working Torque Forward [Max] 900 ft.lbf, 1220 Nm
Power to Wt. Ratio 150 Nm/kg
Air Inlet Thread Size 3/8 in
Impact Mechanism Double Rocking Dog
Hose Diameter [min] (16 Ft Hose Length) 0.5 in
Clutch Lubrication Type Oil Bath
Output Retainer Type Dual
Starting Type Trigger
Torque Reverse [Max] 1400 ft.lbf, 1890 Nm
Vibration 12.8 m/s²
Vibration Uncertainty (K) 14.1 ft/s², 4.3 m/s²
Sound Pressure 110 dB(A)
Torque Limited No
Sound Power 121 dB(A)
Output Drive Size 1 in
Weight 0.0 LB
