SCM Series Medium-Duty 2-Bolt Pillow Block

P2BSCM103

SCM Series Medium-Duty 2-Bolt Pillow Block
Item #100733473
  • 2 Bolts
  • Cast Iron Housing Material
  • Solid Housing Construction
  • Steel Insert Material
SCM Series Medium-Duty 2-Bolt Pillow Block
Price Unavailable
Price Unavailable
Pricing is unavailable at this time. Please contact Customer Service for assistance.
Online Ordering Restricted
Please contact Customer Service for assistance.
Contact Customer Service
    Shipment Options
  • 2 Bolts
  • Cast Iron Housing Material
  • Solid Housing Construction
  • Steel Insert Material

applications

  • Air handling
  • Unit handling
  • Food and beverage
  • Forest products
  • Paper
  • Automotive
  • Chemical
  • Packaging and processing

features

  • Medium-duty utilizes larger rings and housing compared to standard-duty
  • Inner and outer rings are precision hardened and honed for wear resistance and quiet operation
  • DualGuard sealing system includes a mechanically retained, land riding, single lip contact seal plus a patented rubberized flinger for enhanced protection against contaminants
  • Ball cage is made of heat stabilized nylon with fiberglass reinforcement, which allows higher operating temperatures and greater flexibility with added strength
  • Anti-rotation pin makes insert replacement easier with no need to replace grease fittings or location pins
  • 65° set screw spacing offers an optimum balance between locking force and inner ring stress
  • Open and closed safety covers available
Bearing Type Ball Bearing
Bolt to Bolt [Max] 5.44 in
Insert Material Steel
Bolt Hole Spacing Range [Min] 4 11/16 in
Base Height 23/32 in
Bore Length 1.71 in
Lubrication Grease
Shaft Attachment Setscrew
Bearing Design Non-Expansion
Ball Bearing Series 207 Series
Standoff Housing No
Base to Center Height 1.88 in
Series P2BSCM
Bolt Hole Length 15/16 in
Take-Up Frame Size LD-20, TS-250
Speed [Max] 3500 rpm
Base Width 1 3/4 in
Bolt to Bolt [Min] 4.68 in
Inch/Metric Inch Bore
Locking Device Setscrew Locking Inner Ring
Mounted Unit Duty Medium-Duty
Bolt Hole Spacing Range [Max] 5 7/16 in
Housing Material Cast Iron
Bolt Diameter 0.5 in
Base Length 6 1/2 in
Bolt Hole Spacing 5 1/16 in
No. of Bolts 2
Misalignment Range ±2°
End Type Open End
Suitable For Washdown No
Static Load Capacity 3461 lbf
Greasable Yes
Bearing Insert INSSCM103
Dynamic Load Capacity 5759 lbf
Shaft Dia. 1.1875 in
Insert Type Steel Insert
Housing Height 3 3/4 in
Outer Ring Size 207
Length Through Bore 1 17/32 in
Pillow Block Type Thru-Bolt
Sensor Ready Adapter Required
Grease Name Unirex N2
Seal Type Contact Seals
Bolt Holes 2
Housing Construction Solid
Suitable for High Temperature No
Expansion Capability Fixed
Weight 3.37 LB
EAN or UPC 782475593880
