UCP Series Light-Duty Ball Bearing Pillow Block

UCP-1.1/4

UCP Series Light-Duty Ball Bearing Pillow Block
Item #101111250
  • Ball Bearing
  • Pillow Block
  • 1 1/4 in Shaft Diameter
  • 5 1/8 in Bolt Hole Spacing
UCP Series Light-Duty Ball Bearing Pillow Block
Price Unavailable
Price Unavailable
Pricing is unavailable at this time. Please contact Customer Service for assistance.
Online Ordering Restricted
Please contact Customer Service for assistance.
Contact Customer Service
    Shipment Options
  • Ball Bearing
  • Pillow Block
  • 1 1/4 in Shaft Diameter
  • 5 1/8 in Bolt Hole Spacing
Type High Base
Static Load Rating [Max] 3450 lbf
Mounted Unit Duty Light-Duty
Plating Black Oxide
Seal Material Nitrile Rubber
Bearing Type Ball Bearing
Seal Type Contact Seals
Temperature Range [Max] 250 °F
Bearing Width 1.689 in
Center of Bearing from Back of Inner Ring 0.689
Temperature Range [Min] -40 °F
Housing Height 3 21/32 in
Lubrication Relubricatable
Bearing Insert A-UC207-104D1
Bolt Hole Spacing 5 1/8 in
Housing Material Cast Iron
Base Width 1 7/8 in
Shaft Height 1.875 in
Shaft Dia. 1.25 in
Housing No. P207D1V50
Dynamic Load Rating 5800 lbf
Series UCP
Inch/Metric Inch Bore
Housing Length 6 9/16 in
Base Height 23/32 in
End Type Open End
Tightening Torque [Max] 52 in lb
Housing Construction 1 Piece
RPM [Max] 4200 rpm
Housing Width 1 7/8 in
Groove Length 0.96875
Locking Device Setscrew Locking Collar
Weight 4.11 LB
EAN or UPC 4547359222166
