UCP Series Light-Duty Ball Bearing Pillow Block

UCP-1.11/16

UCP Series Light-Duty Ball Bearing Pillow Block
Item #101111253
  • Ball Bearing
  • Pillow Block
  • 1 11/16 in Shaft Diameter
  • 5 7/8 in Bolt Hole Spacing
UCP Series Light-Duty Ball Bearing Pillow Block
Price Unavailable
Price Unavailable
Pricing is unavailable at this time. Please contact Customer Service for assistance.
Online Ordering Restricted
Please contact Customer Service for assistance.
Contact Customer Service
    Shipment Options
  • Ball Bearing
  • Pillow Block
  • 1 11/16 in Shaft Diameter
  • 5 7/8 in Bolt Hole Spacing
Seal Material Nitrile Rubber
Mounted Unit Duty Light-Duty
Type High Base
Series UCP
Bolt Hole Spacing 5 7/8 in
Lubrication Relubricatable
Housing Width 2 1/8 in
Bearing Width 1.9375 in
Housing Length 7 15/32 in
Inch/Metric Inch Bore
Shaft Height 2.125 in
Shaft Dia. 1.6875 in
Housing Material Cast Iron
Dynamic Load Rating 7300 lbf
Housing No. P209D1V50
Temperature Range [Min] -40 °F
Temperature Range [Max] 250 °F
Seal Type Contact Seals
Static Load Rating [Max] 4600 lbf
Tightening Torque [Max] 69 in lb
Bearing Type Ball Bearing
RPM [Max] 3500 rpm
Housing Height 4 3/16 in
Locking Device Setscrew Locking Collar
Bearing Insert A-UC209-111D1
Center of Bearing from Back of Inner Ring 0.748
Base Height 25/32 in
Base Width 2 1/8 in
End Type Open End
Plating Black Oxide
Groove Length 1
Housing Construction 1 Piece
Weight 5.706 LB
EAN or UPC 4547359222197
