AC Motor

Item #104590894
    Shipment Options

Alternate Products

Product details

  • AC Motor
  • Air Compressor Motor Application
  • 5 hp
  • 3450 rpm
  • Single Phase


Enclosure Designation Drip Proof
Poles 2
Motor Application Air Compressor
Full Load Amps 20.8
Drive End Bearing 6205
Rotation Selective CW
Enclosure DP
Insulation F
Hz 60
Frame 145T
Efficiency Group 82.5 %
HP 5
Voltage Rating 230
RPM 3450 rpm
Mounting Rigid Base
Service Factor 1
Phase Single Phase
Frame Material Rolled Steel
Open End Bearing 6203
Weight 49.0 LB
EAN or UPC 691720015704
