High phosphorous electroless nickel plated 52100 steel for exceptional corrosion resistance
High performance triple lip contact seal design provides multi-directional sealing with 304 stainless steel body and flinger to minimize contamination ingress and retain lubrication
High strength composite with reinforced stainless steel bolt ferrules for high load capacity and increased strength around the bolt holes.
Solid construction with machined base was designed for minimal gaps and no fillers
Zone hardened inner ring with 120° spacing setscrew lock with corrosion resistant setscrews
Exclusive locking pin and dimple system provides a direct lubricant into the bearing cavity & ball path instead of around a lubrication groove, prevents outer ring rotation.
Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
Reduced maintenance design with plug and includes Sealmaster® Tapered Lands ensures that lubricant will be easily redirected back to the raceway.
USDA H1 complaint food grade grease
options
Corrosion Resistant - Reduced Maintenance - Lubed for Life
Bolt Center-to-Center Length
3.25 in
Flange Type
4-Bolt Flange
Internal Clearance
Standard
Inner Ring O.D.
1.594 in
Housing Color
Light Gray
Bearing Type
Ball Bearing
T Core
2.5630000000000002
Bolt Center-to-Center Length (in)
3.2500
Special Features
Reduced Maintenance
Speed [Max]
2300 rpm
Bearing Design
Non-Expansion
Bore Size
1.25 in
Centerline to Front Face (in)
0.875
Certifications
IP69K
Overall Height (in)
1.5625
Lubrication
Calcium Sulfonate NLGI 2 NSF H1 Food Grade Grease
Outer Ring Land Profile
Tapered
Inch/Metric
Inch
Measure Units
Inch
Angle of Misalignment
±2°
Backside Shield/Seal
Backside Shield included loose in box
Shaft Dia.
1.25 in
Inner Race Length (in)
1.5
Housing Construction
One Piece
Misalignment Type
Static Only
Bolt Size (in)
0.4375
Operating Temperature [Max]
220 °F
Housing Material
Composite
Bore Size - Inch
1.25
Locking Device
Setscrew Locking Collar
Foot Height (in)
0.53125
Expansion
No
Mounted Unit Duty
Standard Duty
Maximum Operating Temperature
220
Bore Shape
Straight
Insert Material
52100 Bearing Steel, Phosphorus Nickel Coated
Retainer Type
Land Riding
Housing Base
Solid
Overall Height
1.563 in
Platform
PN Gold
Pilot Configuration
No Pilot
Inner Race Heat Treat Method
Zone-Hardened
Relubricatable
No
Inner Ring OD (in)
1.59375
Bolt Size
0.438 in
Seal Type
Triple Lip Contact
Replaceable Insert
Yes
Series
CRFC-PN
Bearing Insert Coating
Phosphorus Nickel
Duty Series
Standard
End Cap
Yes
Foot Height
0.531 in
Inner Race Length
1.5 in
Locking Type
Set Screws
Centerline to Front Face
0.875 in
Insert No.
PN-20R
Weight
1.543 LB
EAN or UPC
662461338698
