Tapered Lands ensures that lubricant will be easily redirected back to the raceway.
USDA H1 complaint food grade grease
Solid construction with machined base was designed for minimal gaps and no fillers
Skwezloc® Concentric locking for near perfect concentricity with fluoropolymer coated collar and corrosion resistant cap screw
Exclusive locking pin and dimple system provides a direct lubricant into the bearing cavity & ball path instead of around a lubrication groove, prevents outer ring rotation.
Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
High quality solid base designed investment cast passivated 316 stainless steel casting providing the highest amount corrosion resistance currently available for stainless steel housings.
High performance triple lip contact seal design provides multi-directional sealing with 304 stainless steel body and flinger to minimize contamination ingress and retain lubrication
High phosphorous electroless nickel plated 52100 steel for exceptional corrosion resistance
options
Corrosion Resistant
Insert Material
52100 Bearing Steel, Phosphorus Nickel Coated
Bore Size - Inch
1
Angle of Misalignment
±2°
Operating Temperature [Max]
220 °F
Housing Base
Solid
Bearing Design
Non-Expansion
Pilot Configuration
No Pilot
Misalignment Type
Static Only
Relubricatable
Yes
Bore Shape
Straight
Inner Race Length
1.375 in
Retainer Type
Land Riding
Platform
PN Gold
Foot Height
0.53 in
Shaft Dia.
1 in
Foot Height (in)
0.53
Locking Type
Concentric
Backside Shield/Seal
Optional backside shield available order separate
Bolt Center-to-Center Length (in)
2.7500
Mounted Unit Duty
Standard Duty
Inch/Metric
Inch
Centerline to Front Face (in)
0.8125
Bolt Center-to-Center Length
2.75 in
Lubrication
Calcium Sulfonate NLGI 2 NSF H1 Food Grade Grease
Expansion
No
Inner Race Heat Treat Method
Zone-Hardened
Bolt Size (in)
0.4375
Centerline to Front Face
0.813 in
Bolt Size
0.438 in
T Core
2.38
Maximum Operating Temperature
220
End Cap
Yes
Flange Type
4-Bolt Flange
Certifications
IP69K
Housing Material
Stainless Steel
Locking Device
Skwezloc® Concentric Collar
Collar OD (in)
1.9375
Housing Color
Silver
Bearing Type
Ball Bearing
Insert No.
PN-16T
Measure Units
Inch
Housing Construction
One Piece
Series
CRFS-PN-T
Inner Race Length (in)
1.375
Internal Clearance
Standard
Duty Series
Standard
Speed [Max]
2700 rpm
Overall Height (in)
1.4375
Outer Ring Land Profile
Standard
Bearing Insert Coating
Phosphorus Nickel
Overall Height
1.438 in
Bore Size
1 in
Collar O.D.
1.938 in
Seal Type
Triple Lip Contact
Replaceable Insert
Yes
Weight
2.1 LB
EAN or UPC
662461347829
