705628 / Gold Line

MFC-23T

705628 / Gold Line
Item #101178766
705628 / Gold Line
Price Unavailable
Price Unavailable
Pricing is unavailable at this time. Please contact Customer Service for assistance.
Online Ordering Restricted
Please contact Customer Service for assistance.
Contact Customer Service
    Shipment Options

description

  • Pilot dimension fits in customer's machine.

features

  • Powder coated epoxy cast iron housing with extended inner ring bearings
  • Skwezloc® concentric locking for near perfect concentricity
  • Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
  • Sealmaster® exclusive lock pin & dimple for direct lubrication and anti-rotation
Duty Series Medium
Inner Race Length (in) 2
Internal Clearance Standard
Cartridge Width 1.39 in
Shaft Dia. 1.4375 in
Bolt Size (in) 0.375
Operating Temperature [Max] 220 °F
O.D. 5.25 in, 133.4 mm
Housing Material Cast Iron
Housing Type Flange, Piloted
Housing Color Gray
Bearing Design Non-Expansion
Bearing Type Ball Bearing
Lubrication Lithium Complex NLGI 2 Grease
Speed [Max] 5850 rpm
Pilot Diameter 3.625 in
Misalignment Type Static Only
Outer Ring Land Profile Standard
Relubricatable Yes
Angle of Misalignment ±2°
Housing OD (in) 5.25
Locking Device Setscrew Locking
Housing O.D. 5.25 in
Flange Type Piloted Flange
End Cap No
Bolt Center Diameter (in) 4.375
Inner Race Length 2 in
Bolt Center-to-Center Length (in) 4.3750
Housing Construction One Piece
Bore Shape Straight
Foot Height 0.438 in
Bore Size - Inch 1.438
Bolt Center Dia. 4.375 in
Collar O.D. 2.688 in
Retainer Type Land Riding
Centerline to Front Face 1.25 in
Pilot Configuration No Pilot
Duty Medium-Duty
Foot Height (in) 0.438
Replaceable Insert Yes
Inner Race Heat Treat Method Zone-Hardened
Insert Material 52100 Bearing Steel, Black Oxided
Locking Type Concentric
Inch/Metric Inch
Pilot Diameter (in) 3.625
Collar OD (in) 2.688
Expansion No
Measure Units Inch
Bearing Insert Coating Black Oxide
Centerline to Front Face (in) 1.25
Insert No. 3-17T
Maximum Operating Temperature 220
Bolt Size 0.375 in
Bore Size 1.438 in
Housing Base Solid
Seal Type Felt Labyrinth
Weight 4.91 LB
EAN or UPC 662461031728
