Straight Bore Tapered Roller Bearings

RPB111-C2

Straight Bore Tapered Roller Bearings
Item #101181634
  • Single Lip Contact Seal Type
Straight Bore Tapered Roller Bearings
Price Unavailable
Price Unavailable
Pricing is unavailable at this time. Please contact Customer Service for assistance.
Online Ordering Restricted
Please contact Customer Service for assistance.
Contact Customer Service
    Shipment Options
  • Single Lip Contact Seal Type

description

  • Standard series bearing used in the widest range of applications.

applications

  • Toughest application conditions
  • Demanding environments

features

  • Heavy duty tapered roller bearings with steel cage for radial, thrust and combined loading
  • Race-mounted contact flinger seal
  • Double-collar interlock with 120° spacing setscrew lock, diamond faceted setscrews
  • Powder coat epoxy 2-bolt split cast iron housing
Bolt Center [Max] 6.438 in
Locking Type Double Collar Mount
Misalignment Type Static Only
Housing Color Gray
End Cap No
Overall Length (in) 7.75
Bore Size - Inch 1.688
Housing Construction Split Two Piece
Foot Height 1.25 in
Collar O.D. 2.875 in
Base to Center Height (in) 2.13
Duty Series Normal
Overall Width 3.38 in
Pillow Block Type 2-Bolt Flange
Lubrication Lithium, EP, NLGI#2
Housing Material Cast Iron
Bolt Center Min (in) 5.563
Internal Clearance Standard
Inner Race Length 3.375 in
Bearing Insert Coating Uncoated
Centerline to Front Face (in) 1.688
Foot Height (in) 1.25
Bolt Size 0.5 in
Outer Ring Land Profile Standard
Housing Base Solid
Bore Size 1.688 in
Inch/Metric Inch
Replaceable Insert Yes
Rolling Element Tapered
Expansion No
Platform RPB Series
Inner Race Heat Treat Method Case Carburized Inner Ring
Bore Shape Straight
Overall Width (in) 3.38
Base Width (in) 2.313
Bolt Center Max (in) 6.438
Series RPB
Angle of Misalignment ±3°
Bolt Center [Min] 5.563 in
Overall Height 4.375 in
Operating Temperature [Max] 220°F
Measure Units Inch
Base to Center Height 2.13 in
Inner Race Length (in) 3.375
Insert Material 52100 Bearing Steel
Bolt Size (in) 0.5
Insert No. RCI-111C
Overall Height (in) 4.375
Radial Dynamic Load Capacity 6140 lb
Retainer Material Steel
Centerline to Front Face 1.688 in
Overall Length 7.75 in
Maximum Operating Temperature 220
Base Width 2.313 in
Brand. Sealmaster
Bolt Center-to-Center Length (in) 6
Seal Type Single Lip Contact
Bolt Center-to-Center Length 6 in
Collar OD (in) 2.875
Relubricatable Yes
Radial Dynamic Load Capacity (lb) 6140
Weight 10.9 LB
EAN or UPC 662288493518
