R Series Small Inch-Size Ball Bearing

R6ZZ

R Series Small Inch-Size Ball Bearing
Item #101174802
  • 3/8" ID x 7/8" OD x 9/32" Wide
  • Double Sealed
  • No Snap Ring
  • Single Row Radial Steel Bearing
R Series Small Inch-Size Ball Bearing
Price Unavailable
Price Unavailable
Pricing is unavailable at this time. Please contact Customer Service for assistance.
Online Ordering Restricted
Please contact Customer Service for assistance.
Contact Customer Service
    Shipment Options
  • 3/8" ID x 7/8" OD x 9/32" Wide
  • Double Sealed
  • No Snap Ring
  • Single Row Radial Steel Bearing

applications

  • Ample radial and thrust capacity for the majority of applications involving heavy radial loads, heavy thrust loads or combinations of these

features

  • Single-row, radial, Conrad-type bearings available in inch sizes for shafts from 1/8" to 1 1/2" in diameter
  • Open, shielded and sealed types available
  • Many sizes available in stainless steel
  • Supplied with ABMA CO radial clearance unless otherwise specified
Lubricant Polyurea Base
Precision Standard
Outer Ring Width 9/32 in
Bore Type Round Bore
I.D. 3/8 in
Limiting Speed - Grease 31000 rpm
O.D. 0.875 in
Temperature Range [Min] -22 °F
Static Load Rating [Max] 301 lbf
Precision Level Standard (ABEC 1)
Origin Single Row Radial
Inch/Metric Inch Bore
Closed Width 9/32 in
Material Steel
Temperature Range [Max] 250 °F
O.D. Type Straight
Fillet Radius 0.016 in
Bearing Type Radial
Cage Material Steel
Contact Angle 0°
Seal Type Contact Seals
Seal Material Rubber
Radial Internal Clearance Specification Normal Clearance
Rows of Balls Single
Cage Type Metal
Snap Ring No Snap Ring
Open Width 7/32 in
Limiting Speed - Sealed 21000 rpm
Enclosure Double Sealed
Preload Level None
Locking Device No Locking Device
No. in Set Single Bearing
Limiting Speed - Oil 38000 rpm
Radial Internal Clearance Normal
Ball Material Steel
icNumber 7696119
Inner Ring Width 9/32 in
Capacity Standard Capacity
Dynamic Load Rating 746 lbf
Weight 0.042 LB
EAN or UPC 97741021937
NSN Number 3110-00-520-3877
