R Series Small Inch-Size Ball Bearing

R8ZZ

R Series Small Inch-Size Ball Bearing
Item #100755634
  • 1/2" ID x 1 1/8" OD x 5/16" Wide
  • Double Sealed
  • No Snap Ring
  • Single Row Radial Steel Bearing
R Series Small Inch-Size Ball Bearing
Price Unavailable
Price Unavailable
Pricing is unavailable at this time. Please contact Customer Service for assistance.
Online Ordering Restricted
Please contact Customer Service for assistance.
Contact Customer Service
    Shipment Options
  • 1/2" ID x 1 1/8" OD x 5/16" Wide
  • Double Sealed
  • No Snap Ring
  • Single Row Radial Steel Bearing

applications

  • Ample radial and thrust capacity for the majority of applications involving heavy radial loads, heavy thrust loads or combinations of these

features

  • Single-row, radial, Conrad-type bearings available in inch sizes for shafts from 1/8" to 1 1/2" in diameter
  • Open, shielded and sealed types available
  • Many sizes available in stainless steel
  • Supplied with ABMA CO radial clearance unless otherwise specified
Precision Level Standard (ABEC 1)
Static Load Rating [Max] 540 lbf
Inner Ring Width 5/16 in
I.D. 1/2 in
Dynamic Load Rating 1140 lbf
Origin Single Row Radial
Cage Material Steel
O.D. 1.125 in
Locking Device No Locking Device
Enclosure Double Sealed
Lubricant Polyurea Base
Bore Type Round Bore
Seal Material Rubber
Snap Ring No Snap Ring
O.D. Type Straight
Limiting Speed - Grease 24000 rpm
Radial Internal Clearance Normal
Closed Width 5/16 in
Capacity Standard Capacity
Precision Standard
Outer Ring Width 5/16 in
Seal Type Contact Seals
No. in Set Single Bearing
Rows of Balls Single
Ball Material Steel
Temperature Range [Min] -22 °F
Bearing Type Radial
Open Width 1/4 in
Material Steel
Temperature Range [Max] 250 °F
icNumber 7696115
Radial Internal Clearance Specification Normal Clearance
Cage Type Metal
Inch/Metric Inch Bore
Limiting Speed - Oil 29000 rpm
Contact Angle 0°
Limiting Speed - Sealed 16000 rpm
Fillet Radius 0.016 in
Preload Level None
Weight 0.066 LB
EAN or UPC 97741022019
NSN Number 3110-00-850-4811
