These chains provide a high quality conveying medium for material handling equipment, road building machinery, farming implements, baking, packaging and bottling equipment.
applications
Severe operating conditions
Low speed
Relatively long center distances
Heavy load
features
Long lasting, heat-treated, solid rollers
Heat-treated pins that are fabricated from high grade steel
Higher horsepower capacity
Built to handle shock loads
Complies with RoHS restrictions on the use of certain hazardous substances in electrical and electronic equipment
No. of Strands Across
1
Roller Width
1/2 in
Link Plates Thickness
1/8 in
Pins & Rollers
Standard
Self-Lubricating
No
Chain Pitch
1 1/2 in
Average Tensile Strength
9040 lb
Number of Links per 10 ft
80
Pitch
1.5 in
Chain No.
2060
Pin Diameter
0.234 in
Material
Carbon Steel
Pin Material
Carbon Steel
Chain Series
2060, 2062, 2068, 2069
Side Bow
No
Chain Type
Standard Roller
Package Type
10 Foot Box
Pin Overall Length
1.225 in
Roller Dia.
0.469 in
Maximum Allowable Load
1410 lb
Width Between Roller Link Plates
0.5 in
Rated Working Load
1,410 lb
Chain Construction
Riveted
Link Plates Height
0.677 in
Duty
Heavy Series
Standard Connection
Spring Clip Type
Weight
1.05 LB
EAN or UPC
97039181336
Pre-Packed Quantities
