- TEFC Enclosure
- 1 hp
- 60 Hz Frequency
- 145T Frame
description
Baldor-Reliance® severe duty motors include features designed to protect against contamination, moisture, vibration and corrosion. These motors use Super-E® premium efficient electrical designs which are built to handle demanding duty cycles, provide high starting and peak torques, and operate over wide speed ranges. Severe Duty motors provide safe, long operating life, reliable performance, and reduced energy consumption in the toughest applications.
features
- Heavy duty cast iron construction
- Premium efficient electrical designs
- Enhanced ingress protection
- Corrosion resistant epoxy finish
| Enclosure | TEFC |
| Voltage Rating | 208-230/460 |
| Frequency | 60 Hz |
| Full Load Current | 3.4 A/1.7 A |
| Frame Size | 145T |
| Service Factor | 1.15 |
| Frame Material | Iron |
| Efficiency | 82.5% |
| Shaft Rotation | Reversible |
| Motor Application | Severe Duty |
| Shaft Dia. | 0.875 in |
| Duty Cycle | Continuous |
| Conduit Box Material | Cast Iron |
| Base | Rigid |
| Mount Type | F-1 |
| Insulation Class | F |
| Shaft Grounding | No |
| Power Factor | 66 |
| Speed | 1160 rpm |
| Phase | Three Phase |
| Frame | 145T |
| HP [Min] | 1 |
| Overall Length | 12.54 in |
| HP | 1 |
| Model | XT |
| Synchronous | 1200 rpm |
| Inverter Duty | Inverter Duty |
| NEMA Design | B |
| End Plate | Standard |
| RPM | 1200 rpm |
| Standard | CCSA US, CSA EEV, NEMA_PREMIUM, UR, NEMA |
| Poles | 6 |
| Ambient Temperature | 104 °F |
| Mounting | Foot Mounted |
| Voltage | 575 V |
| Weight | 56.0 LB |
| EAN or UPC | 781568960615 |
