Narrow Inner Ring Ductile Iron Housing Material Pillow Block

BPW205-15

Narrow Inner Ring Ductile Iron Housing Material Pillow Block
Item #101403296
  • 15/16 in Shaft Diameter
  • 1 7/16 in Center Line To Base Dimension
  • 3 11/16 in Bolt Hole Spacing Range [MIN]
Narrow Inner Ring Ductile Iron Housing Material Pillow Block
Price Unavailable
Price Unavailable
Pricing is unavailable at this time. Please contact Customer Service for assistance.
Online Ordering Restricted
Please contact Customer Service for assistance.
Contact Customer Service
    Shipment Options
  • 15/16 in Shaft Diameter
  • 1 7/16 in Center Line To Base Dimension
  • 3 11/16 in Bolt Hole Spacing Range [MIN]
Pillow Block Type Thru-Bolt
Shaft Dia. 0.9375 in
Bolt Hole Spacing Range [Min] 3 11/16 in
Housing Material Ductile Iron
Duty Series Normal
Bolt Hole Width 7/16 in
Locking Device Setscrew Locking Collar
Series BPW200
Bearing Design Non-Expansion
Housing No. PW205
Base Length 5 1/8 in
Lubrication Relubricatable
Bolt Hole Spacing Range [Max] 4 3/16 in
End Type Open End
Bolt Hole Length 5/8 in
Bearing Type Ball Bearing
Base Width 1 1/8 in
Insert Material AISI 52100 Steel
Housing PW205
Bolt Size 3/8 in
Seal Type Contact Seals
Bolt Holes 2
Length Through Bore 1.063 in
Bolt Hole Spacing 3 15/16 in
Housing Height 2 45/64 in
Mounted Unit Duty Normal-Duty
Relubricatable Yes
Inch/Metric Inch Bore
Housing Construction 1 Piece
Base Height 11/32 in
Locking Style Set Screw
Lubrication Fitting Tap 1/4-28 UNF
Weight 1.18 LB
EAN or UPC 808250107797
