Continental
FT 1710-38 RS UNF
R Series Natural Rubber Compound Ring Model Air Spring
Item #112370687
- Triple Convolution Air Spring
- 2-Ply Bellows
- Style #320
- Ribbed Neck Aluminum Bead Rings, Equal Spacing, 1 7/8" Bolts
- Type 4 Bead Ring End Closure
description
- Firestone air springs are time-proven industrial actuators and vibration isolators. As an actuator, air springs offer a unique ability to provide linear or angular motion in a very low profile when compared to air cylinders. Their unique, flexible properties lend well to numerous duties on machines that press, tension, roll, convey, lift and package. As an isolator, air springs are effective in reducing the harmful effects of vibration.
applications
- Industrial actuator
- Vibration isolator
- Press machines
- Conveyors
- Lifts
- Packaging machines
features
- Two-ply, fabric-reinforced rubber
- Temperature ranges from -35 °F to 135 °F
- Maximum pressure 100 psig
- Flexible media
- Provides linear and angular motion
- Reduces harmful effects of vibration
| Force @ 8 in Stroke | N/A |
| Temperature Range [Max] | 135 °F |
| Stroke Length [Max] | 11.800 in |
| Air Inlet Type | NPT |
| Air Spring Description | Ribbed Neck Aluminum Bead Rings, Equal Spacing, 1 7/8" Bolts |
| Bellows Type | Triple Convoluted |
| Style No. | 320 |
| Force @ 9 in Stroke | N/A |
| No. of Bolts | 24 |
| Bumpers | w/o Bumpers |
| Temperature Range [Min] | -35 °F |
| Force @ Stroke (80 psi) | 26700 lbf @ 3 in, 28700 lbf @ 1 in |
| Force @ 4 in Stroke | N/A |
| Bolt Circle Dia. | 19 in |
| Force @ 2 in Stroke | N/A |
| Force @ 12 in Stroke | N/A |
| Convolutions | Triple |
| Force @ 1 in Stroke | 28700 lbf |
| Force @ 3 in Stroke | 26700 lbf |
| Compressed Height | 4 1/2 in |
| Force @ 5 in Stroke | N/A |
| Pressure [Max] | 100 psi |
| Force @ Maximum Stroke (80 psi) | 17390 lbf |
| End Closure | Type 4 Bead Ring |
| Force @ 6 in Stroke | N/A |
| Weight | 36.3 LB |
| EAN or UPC | 767555004500 |
