LS Series Four-Piece Special Purpose Precision Spherical Bearing

LS8

LS Series Four-Piece Special Purpose Precision Spherical Bearing
Item #101993579
  • 1/2" ID x 1 5/16" OD x 11/16" Inner Ring Width
  • 17/32" Outer Ring Width
  • Unsealed Spherical Plain Bearing
LS Series Four-Piece Special Purpose Precision Spherical Bearing
Price Unavailable
Price Unavailable
Pricing is unavailable at this time. Please contact Customer Service for assistance.
Online Ordering Restricted
Please contact Customer Service for assistance.
Contact Customer Service
    Shipment Options
  • 1/2" ID x 1 5/16" OD x 11/16" Inner Ring Width
  • 17/32" Outer Ring Width
  • Unsealed Spherical Plain Bearing
Outer Race Material Carbon Steel, Protective Coated for Corrosion Resistance
Ball Material 52100 Alloy Steel
Static Load Rating [Max] 15600 lbf
Lubrication Type Requires Relubrication
Angle of Misalignment 7.5 degrees
Enclosure Open
Operating Temperature [Max] 300 ⁰F
Axial Static Load Rating 4303 lbf
Housing Bore Size [Min] 1.313 in
Spherical Diameter 0.931 in
O.D. 1.313 in, 33.34 mm
Operating Temperature [Min] -30 ⁰F
Self-Lubricating No
Ball Flat Dia. 0.627 in
Inner Ring Width 11/16 in
Series Heim®
Static Load Rating 15600 lbf, 69392 N
I.D. 0.5 in, 12.7 mm
Outside Ring Width 0.531 in, 13.49 mm
Inside Ring Width 0.687 in, 17.45 mm
Type Spherical
Insert Material N/A
Inch/Metric Inch
Ball Dia. 0.937 in, 23.8 mm
Liner Material Brass
Material 52100 Bearing Quality Steel
Style Four Piece - Metal to Metal
Outer Ring Width 17/32 in
Weight 0.18 LB
EAN or UPC 637400158101
