- 1 1/2 in Gauge Size
- 0 to 30 psi Pressure Range
- NPT Connection Type
- Black painted steel with chrome triangular bezel and U-clamp Material
features
- Accurate and reliable general purpose dry gauge with vacuum & compound ranges, and ABS or Steel case. Ideal for applications including hydraulics, pneumatics, medical, pumps, compressors, refrigeration controls and more.
Multiple connection options are available including panel mount. A wide variety of pressure ranges, scale options, connections sizes, and options including flanges, case options, cover rings, lens materials, pointers, and orifices are also available.
Cleaning for Oxygen Service (O2) is available only for dry or HL (Halocarbon) filled gauges.
| Case Type | Steel Case Panel Mount |
| Pressure Range | 0 to 30 psi |
| Ambient Temperature Range [Max] | 140 °F |
| Display Size | White Background with Black Primary Scale and Red Secondary Scale. UV Resistant. |
| Lens/Display Material | Acrylic |
| Type | Dry Pressure Gauge |
| Accuracy | 2.5 % |
| Ambient Temperature Range [Min] | -40 °F |
| Bezel Material | Chrome-Plated Steel |
| Material | Black painted steel with chrome triangular bezel and U-clamp |
| Connection Size | 1/8 in |
| Connection Type | NPT |
| Media Temperature [Max] | 140 °F |
| Connection Material | Brass |
| Warranty | 1 Year |
| Measuring Element | Copper Alloy Bourdon Tube |
| Pointer | Molded Plastic |
| Connection Location | Back |
| Gauge Size | 1 1/2 in |
| Media Temperature [Min] | -4 °F |
| Weight | 0.0 LB |
