High phosphorous electroless nickel plated 52100 steel for exceptional corrosion resistance
High performance triple lip contact seal design provides multi-directional sealing with 304 stainless steel body and flinger to minimize contamination ingress and retain lubrication
High quality solid base designed investment cast passivated 316 stainless steel casting providing the highest amount corrosion resistance currently available for stainless steel housings.
Solid construction with machined base was designed for minimal gaps and no fillers
Zone hardened inner ring with 120° spacing setscrew lock with corrosion resistant setscrews
Exclusive locking pin and dimple system provides a direct lubricant into the bearing cavity & ball path instead of around a lubrication groove, prevents outer ring rotation.
Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
Tapered Lands ensures that lubricant will be easily redirected back to the raceway.
USDA H1 complaint food grade grease
options
Corrosion Resistant
Bolt Center-to-Center Length (in)
3.8910
Housing Material
Stainless Steel
End Cap
Yes
Overall Width (in)
2.75
Housing Base
Solid
Overall Width
2.75 in
Outer Ring Land Profile
Standard
Insert No.
PN-16
Flange Type
2-Bolt Flange
Centerline to Front Face (in)
0.813
Radial Dynamic Load Capacity
2801 lb
Seal Type
Triple Lip Contact
Foot Height (in)
0.531
Locking Type
Set Screws
Bore Shape
Straight
Overall Height to Inner Ring
1.435 in
Shaft Dia.
1 in
Inner Ring OD (in)
1.375
Overall Height (in)
1.4375
Lubrication
Calcium Sulfonate NLGI 2 NSF H1 Food Grade Grease
Pilot Configuration
No Pilot
Bolt Center-to-Center Length
3.891 in
Retainer Type
Land Riding
Replaceable Insert
Yes
Bore Size
1 in
Bearing Type
Ball Bearing
Length Through Bore (in)
1.375
Radial Dynamic Load Capacity (lb)
2801
Relubricatable
Yes
Operating Temperature [Max]
220 °F
Mounted Unit Duty
Standard Duty
Inner Ring O.D.
1.375 in
Inch/Metric
Inch
Housing Construction
One Piece
Housing Width
2.75 in
Bolt Size (in)
0.4375
Foot Height
0.531 in
Certifications
IP69K
Insert Material
52100 Bearing Steel, Phosphorus Nickel Coated
Series
CRBFTS
Platform
PN Gold
Bolt Size
0.438 in
Internal Clearance
Standard
Bearing Design
Non-Expansion
Inner Race Length (in)
1.375
Backside Shield/Seal
Backside Shield included loose in box
Inner Race Length
1.375 in
Duty Series
Standard
Misalignment Type
Static Only
Housing Width (in)
2.75
Expansion
No
Centerline to Front Face
0.813 in
Measure Units
Inch
Overall Height
1.438 in
Overall Length
4.875 in
Bore Size - Inch
1
Radial Static Load Capacity (lb)
1651
Angle of Misalignment
±2°
Overall Length (in)
4.875
Overall Height to Inner Ring (in)
1.435
Inner Race Heat Treat Method
Zone-Hardened
Bearing Insert Coating
Phosphorus Nickel
Maximum Operating Temperature
220
Housing Color
Silver
Speed [Max]
2700 rpm
Weight
1.6 LB
EAN or UPC
662461341223
