High phosphorous electroless nickel plated 52100 steel for exceptional corrosion resistance
High performance triple lip contact seal design provides multi-directional sealing with 304 stainless steel body and flinger to minimize contamination ingress and retain lubrication
Tapered Lands ensures that lubricant will be easily redirected back to the raceway.
USDA H1 complaint food grade grease
Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
Zone hardened inner ring with 120° spacing setscrew lock with corrosion resistant setscrews
Exclusive locking pin and dimple system provides a direct lubricant into the bearing cavity & ball path instead of around a lubrication groove, prevents outer ring rotation.
High quality solid base designed investment cast passivated 316 stainless steel casting providing the highest amount corrosion resistance currently available for stainless steel housings.
Solid construction with machined base was designed for minimal gaps and no fillers
options
Corrosion Resistant
Misalignment Type
Static Only
Operating Temperature [Max]
220 °F
Centerline to Front Face (in)
1
Inner Ring OD (in)
1.859
Housing Color
Silver
Maximum Operating Temperature
220
Pilot Configuration
No Pilot
Foot Height
0.563 in
Lubrication
Calcium Sulfonate NLGI 2 NSF H1 Food Grade Grease
Bolt Center-to-Center Length (in)
5.1250
Duty Series
Standard
Overall Length
6.125 in
Inch/Metric
Inch
Bearing Type
Ball Bearing
Bearing Insert Coating
Phosphorus Nickel
Inner Ring O.D.
1.859 in
Measure Units
Inch
Overall Height to Inner Ring (in)
1.748
Overall Length (in)
6.125
Mounted Unit Duty
Standard Duty
Expansion
No
Foot Height (in)
0.563
Series
CRBFTS
Internal Clearance
Standard
Speed [Max]
2000 rpm
Insert No.
PN-23
Housing Construction
One Piece
Relubricatable
Yes
Housing Base
Solid
Bearing Design
Non-Expansion
Centerline to Front Face
1 in
Outer Ring Land Profile
Standard
Bolt Size
0.5 in
Bore Shape
Straight
Backside Shield/Seal
Backside Shield included loose in box
Flange Type
2-Bolt Flange
Bolt Center-to-Center Length
5.125 in
Certifications
IP69K
Inner Race Heat Treat Method
Zone-Hardened
Bore Size - Inch
1.438
Shaft Dia.
1.4375 in
Replaceable Insert
Yes
Bolt Size (in)
0.5
End Cap
Yes
Insert Material
52100 Bearing Steel, Phosphorus Nickel Coated
Seal Type
Triple Lip Contact
Housing Material
Stainless Steel
Platform
PN Gold
Overall Height to Inner Ring
1.748 in
Locking Type
Set Screws
Bore Size
1.438 in
Angle of Misalignment
±2°
Retainer Type
Land Riding
Weight
3.2 LB
EAN or UPC
662461341483
