High phosphorous electroless nickel plated 52100 steel for exceptional corrosion resistance
High performance triple lip contact seal design provides multi-directional sealing with 304 stainless steel body and flinger to minimize contamination ingress and retain lubrication
High strength composite with reinforced stainless steel bolt ferrules for high load capacity and increased strength around the bolt holes.
Solid construction with machined base was designed for minimal gaps and no fillers
Zone hardened inner ring with 120° spacing setscrew lock with corrosion resistant setscrews
Exclusive locking pin and dimple system provides a direct lubricant into the bearing cavity & ball path instead of around a lubrication groove, prevents outer ring rotation.
Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
Tapered Lands ensures that lubricant will be easily redirected back to the raceway.
options
Corrosion Resistant
Mounted Unit Duty
Standard Duty
Bearing Insert Coating
Phosphorus Nickel
Speed [Max]
3100 rpm
Insert No.
PN-12
Relubricatable
Yes
Misalignment Type
Static Only
Bore Shape
Straight
Foot Height
0.438 in
Seal Type
Triple Lip Contact
Retainer Type
Land Riding
Maximum Operating Temperature
220
Measure Units
Inch
Insert Material
52100 Bearing Steel, Phosphorus Nickel Coated
Bolt Center-to-Center Length
3.531 in
Inch/Metric
Inch
Backside Shield/Seal
Optional backside shield available order separate
Replaceable Insert
Yes
Series
CRFTC-PN
End Cap
Yes
Overall Height to Inner Ring (in)
1.281
Bore Size - Inch
0.75
Expansion
No
Bearing Type
Ball Bearing
Internal Clearance
Standard
Centerline to Front Face
0.719 in
Shaft Dia.
0.75 in
Housing Material
Composite
Duty Series
Standard
Locking Device
Setscrew Locking Collar
Lubrication
Calcium Sulfonate NLGI 2 NSF H1 Food Grade Grease
Platform
PN Gold
Foot Height (in)
0.438
Bolt Size (in)
0.375
Flange Type
2-Bolt Flange
Housing Color
Light Gray
Centerline to Front Face (in)
0.719
Housing Base
Solid
Overall Length (in)
4.469
Bearing Design
Non-Expansion
Outer Ring Land Profile
Standard
Operating Temperature [Max]
220 °F
Angle of Misalignment
±2°
Locking Type
Set Screws
Inner Ring OD (in)
1.188
Housing Construction
One Piece
Pilot Configuration
No Pilot
Overall Length
4.469 in
Inner Ring O.D.
1.188 in
Bolt Size
0.375 in
Overall Height to Inner Ring
1.281 in
Bore Size
0.75 in
Inner Race Heat Treat Method
Zone-Hardened
Certifications
IP69K
Bolt Center-to-Center Length (in)
3.5310
Weight
0.7 LB
EAN or UPC
662461336922
