High phosphorous electroless nickel plated 52100 steel for exceptional corrosion resistance
High performance triple lip contact seal design provides multi-directional sealing with 304 stainless steel body and flinger to minimize contamination ingress and retain lubrication
High strength composite with reinforced stainless steel bolt ferrules for high load capacity and increased strength around the bolt holes.
Skwezloc® Concentric locking for near perfect concentricity with fluoropolymer coated collar and corrosion resistant cap screw
Exclusive locking pin and dimple system provides a direct lubricant into the bearing cavity & ball path instead of around a lubrication groove, prevents outer ring rotation.
Solid construction with machined base was designed for minimal gaps and no fillers
Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
Tapered Lands ensures that lubricant will be easily redirected back to the raceway.
USDA H1 complaint food grade grease
options
Corrosion Resistant
Overall Width (in)
2.719
Housing Width
2.719 in
Mounted Unit Duty
Standard Duty
Bearing Insert Coating
Phosphorus Nickel
Inner Race Length (in)
1.43
Overall Height
1.438 in
Expansion
No
Relubricatable
Yes
Angle of Misalignment
±2°
Collar OD (in)
1.9375
End Cap
Yes
Bore Size - Inch
1
Length Through Bore (in)
1.43
Insert Material
52100 Bearing Steel, Phosphorus Nickel Coated
Overall Height to Inner Ring
1.438 in
Shaft Dia.
1 in
Bore Size
1 in
Overall Height to Inner Ring (in)
1.438
Collar O.D.
1.938 in
Overall Height (in)
1.4375
Pilot Configuration
No Pilot
Maximum Operating Temperature
220
Seal Type
Triple Lip Contact
Inner Race Heat Treat Method
Zone-Hardened
Replaceable Insert
Yes
Bolt Center-to-Center Length
3.891 in
Housing Base
Solid
Bolt Center-to-Center Length (in)
3.8910
Locking Device
Skwezloc® Concentric Collar
Housing Color
Light Gray
Overall Length (in)
4.938
Foot Height
0.531 in
Certifications
IP69K
Foot Height (in)
0.531
Internal Clearance
Standard
Inch/Metric
Inch
Housing Material
Composite
Measure Units
Inch
Overall Width
2.719 in
Retainer Type
Land Riding
Radial Static Load Capacity (lb)
1651
Misalignment Type
Static Only
Outer Ring Land Profile
Standard
Radial Dynamic Load Capacity
2801 lb
Bolt Size (in)
0.4375
Flange Type
2-Bolt Flange
Housing Width (in)
2.719
Bearing Type
Ball Bearing
Backside Shield/Seal
Optional backside shield available order separate
Radial Dynamic Load Capacity (lb)
2801
Operating Temperature [Max]
220 °F
Series
CRFTC-PN
Bolt Size
0.438 in
Bearing Design
Non-Expansion
Speed [Max]
2700 rpm
Insert No.
PN-16T
Housing Construction
One Piece
Locking Type
Concentric
Overall Length
4.938 in
Inner Race Length
1.43 in
Duty Series
Standard
Lubrication
Calcium Sulfonate NLGI 2 NSF H1 Food Grade Grease
Platform
PN Gold
Bore Shape
Straight
Weight
0.925 LB
EAN or UPC
662461338841
