High phosphorous electroless nickel plated 52100 steel for exceptional corrosion resistance
High performance triple lip contact seal design provides multi-directional sealing with 304 stainless steel body and flinger to minimize contamination ingress and retain lubrication
High quality solid base designed investment cast passivated 316 stainless steel casting providing the highest amount corrosion resistance currently available for stainless steel housings.
Solid construction with machined base was designed for minimal gaps and no fillers
Zone hardened inner ring with 120° spacing setscrew lock with corrosion resistant setscrews
Exclusive locking pin and dimple system provides a direct lubricant into the bearing cavity & ball path instead of around a lubrication groove, prevents outer ring rotation.
Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
Tapered Lands ensures that lubricant will be easily redirected back to the raceway.
USDA H1 complaint food grade grease
options
Corrosion Resistant
Bolt Size (in)
0.5
Locking Type
Set Screws
Angle of Misalignment
±2°
Housing Length
6 3/4 in
Speed [Max]
1750 rpm
Inner Ring O.D.
2.063 in
Bearing Type
Ball Bearing
Measure Units
Inch
Shaft Dia.
1.5 in
Mounted Unit Duty
Standard Duty
Platform
PN Gold
Overall Length (in)
6.75
Bore Shape
Straight
Housing Color
Silver
Locking Device
Setscrew Locking Collar
Insert Material
52100 Bearing Steel, Phosphorus Nickel Coated
Retainer Type
Land Riding
Bearing Design
Non-Expansion
Radial Dynamic Load Capacity
7340 lb
Backside Shield/Seal
Optional backside shield available order separate
Bolt Hole Spacing
5 21/32 in
Outer Ring Land Profile
Standard
Internal Clearance
Standard
Foot Height
0.563 in
Overall Height to Inner Ring
2.016 in
Series
CRFTS
Centerline to Front Face (in)
1.188
Overall Length
6.75 in
Centerline to Front Face
1.188 in
Misalignment Type
Static Only
Bolt Center-to-Center Length (in)
5.6560
Bore Size
1.5 in
Bolt Circle Dia.
5 21/32 in
Housing Base
Solid
Bolt Size
0.5 in
End Cap
Yes
Inch/Metric
Inch
Housing Material
Stainless Steel
Bearing Insert Coating
Phosphorus Nickel
Operating Temperature [Max]
220 °F
Foot Height (in)
0.563
Inner Ring OD (in)
2.063
Housing Construction
One Piece
Relubricatable
Yes
Inner Race Heat Treat Method
Zone-Hardened
Certifications
IP69K
Seal Type
Triple Lip Contact
Maximum Operating Temperature
220
Flange Type
2-Bolt Flange
Insert No.
PN-24
Bolt Center-to-Center Length
5.656 in
End Type
Open End
Overall Height to Inner Ring (in)
2.016
Lubrication
Calcium Sulfonate NLGI 2 NSF H1 Food Grade Grease
Duty Series
Standard
Expansion
No
Bore Size - Inch
1.5
Pilot Configuration
No Pilot
Replaceable Insert
Yes
Weight
4.445 LB
EAN or UPC
662461335789
