Solid construction with machined base was designed for minimal gaps and no fillers
High quality solid base designed investment cast passivated 316 stainless steel casting providing the highest amount corrosion resistance currently available for stainless steel housings.
High phosphorous electroless nickel plated 52100 steel for exceptional corrosion resistance
High performance triple lip contact seal design provides multi-directional sealing with 304 stainless steel body and flinger to minimize contamination ingress and retain lubrication
Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
Tapered Lands ensures that lubricant will be easily redirected back to the raceway.
USDA H1 complaint food grade grease
Skwezloc® Concentric locking for near perfect concentricity with fluoropolymer coated collar and corrosion resistant cap screw
Exclusive locking pin and dimple system provides a direct lubricant into the bearing cavity & ball path instead of around a lubrication groove, prevents outer ring rotation.
options
Corrosion Resistant
Housing Color
Silver
End Type
Open End
Bolt Circle Dia.
7 1/4 in
Bearing Type
Ball Bearing
Maximum Operating Temperature
220
Centerline to Front Face (in)
4.375
Housing Material
Stainless Steel
Outer Ring Land Profile
Standard
Certifications
IP69K
Lubrication
Calcium Sulfonate NLGI 2 NSF H1 Food Grade Grease
Foot Height (in)
0.813
Mounted Unit Duty
Standard Duty
Bolt Size (in)
0.625
Relubricatable
Yes
Bore Size
2 in
Bearing Design
Non-Expansion
Locking Device
Skwezloc® Concentric Collar
Bore Size - Inch
2
Series
CRFTS
Overall Length (in)
8.5
Measure Units
Inch
Operating Temperature [Max]
220 °F
Radial Dynamic Load Capacity
9752 lb
End Cap
Yes
Pilot Configuration
No Pilot
Centerline to Front Face
4.375 in
Collar O.D.
3.5 in
Insert Material
52100 Bearing Steel, Phosphorus Nickel Coated
Duty Series
Standard
Housing Construction
One Piece
Inner Race Heat Treat Method
Zone-Hardened
Overall Height to Inner Ring (in)
2.313
Retainer Type
Land Riding
Replaceable Insert
Yes
Bolt Center-to-Center Length (in)
7.2500
Platform
PN Gold
Bolt Hole Spacing
7 1/4 in
Bolt Size
0.625 in
Insert No.
PN-32T
Bolt Center-to-Center Length
7.25 in
Shaft Dia.
2 in
Collar OD (in)
3.5
Locking Type
Concentric
Bearing Insert Coating
Phosphorus Nickel
Bore Shape
Straight
Overall Length
8.5 in
Speed [Max]
1350 rpm
Expansion
No
Overall Height to Inner Ring
2.313 in
Foot Height
0.813 in
Housing Base
Solid
Housing Length
8 1/2 in
Internal Clearance
Standard
Misalignment Type
Static Only
Flange Type
2-Bolt Flange
Seal Type
Triple Lip Contact
Angle of Misalignment
±2°
Inch/Metric
Inch
Weight
8.4 LB
EAN or UPC
662461347980
