Sealmaster® exclusive lock pin & dimple for direct lubrication and anti-rotation
Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
Reduced maintenance design with plug and includes Sealmaster® Tapered Lands ensures that lubricant will be easily redirected back to the raceway.
Skwezloc® concentric locking for near perfect concentricity
Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
Powder coated epoxy cast iron housing with extended inner ring bearings
options
Reduced Maintenance - Lubed for Life
Lubrication
Lithium Complex NLGI 2 Grease
Bolt Center-to-Center Length
5.125 in
Housing Length
6 1/8 in
Foot Height
0.563 in
Bolt Hole Spacing
5 1/8 in
Expansion
No
Pilot Configuration
No Pilot
Bearing Design
Non-Expansion
Insert Material
52100 Bearing Steel, Black Oxided
Outer Ring Land Profile
Tapered
Bearing Insert Coating
Black Oxide
Overall Height to Inner Ring
1.813 in
Seal Type
Felt Labyrinth
Bolt Size
0.5 in
Housing Construction
One Piece
Series
SFT-T
Flange Type
2-Bolt Flange
Bearing Type
Ball Bearing
Locking Device
Skwezloc® Concentric Collar
Bolt Circle Dia.
5 1/8 in
Shaft Dia.
1.4375 in
Bore Shape
Straight
Bolt Center-to-Center Length (in)
5.1250
Replaceable Insert
Yes
Bore Size - Inch
1.438
Misalignment Type
Static Only
Maximum Operating Temperature
220
Housing Color
Gray
End Cap
No
Speed [Max]
6500 rpm
Angle of Misalignment
±2°
Housing Material
Cast Iron
Relubricatable
No
Inch/Metric
Inch
Overall Height to Inner Ring (in)
1.813
Housing Base
Solid
End Type
Open End
Collar OD (in)
2.5625
Locking Type
Concentric
Inner Race Heat Treat Method
Zone-Hardened
Overall Length
6.125 in
Centerline to Front Face
1.063 in
Measure Units
Inch
Special Features
Reduced Maintenance
Mounted Unit Duty
Standard Duty
Retainer Type
Land Riding
Insert No.
2-17T RM
Collar O.D.
2.563 in
Platform
Gold Line Ball Bearing
Centerline to Front Face (in)
1.063
Bore Size
1.438 in
Internal Clearance
Standard
Bolt Size (in)
0.5
Overall Length (in)
6.125
Duty Series
Standard
Foot Height (in)
0.563
Operating Temperature [Max]
220 °F
Weight
3.5 LB
EAN or UPC
662461343852
