SCJ Standard Series 4-Bolt Flange Unit

SCJ3/4

SCJ Standard Series 4-Bolt Flange Unit
Item #101020289
  • SCJ Standard Series 4-Bolt Flange Unit
  • 0.75 in Shaft
  • Non-Expansion
  • Ball Bearing
  • Cast Iron Housing
  • Contact Seals
  • Setscrew Locking Collar
+ Show More + Show Less
SCJ Standard Series 4-Bolt Flange Unit
Price Unavailable
Price Unavailable
Pricing is unavailable at this time. Please contact Customer Service for assistance.
Online Ordering Restricted
Please contact Customer Service for assistance.
Contact Customer Service
    Shipment Options
  • SCJ Standard Series 4-Bolt Flange Unit
  • 0.75 in Shaft
  • Non-Expansion
  • Ball Bearing
  • Cast Iron Housing

description

  • The Fafnir SCJ flange cartridges are furnished assembled and ready for mounting by means of four bolts through the flange. SCJ Series are ideal for applications where minimum shaft length is required.The units are assembled with GYA-RRB bearings with positive contact land riding seals and setscrew locking.These units are factory prelubricated, but a grease fitting is provided for relubrication if required.

applications

  • Agriculture
  • Fans and blowers
  • Food processing
  • Conveyors
Shaft Dia. 0.75 in
Flange Type 4-Bolt Flange
Duty Normal-Duty
Overall Width 1 1/8 in
Housing Material Cast Iron
Mounted Unit Duty Standard Duty
Bearing Design Non-Expansion
Inch/Metric Inch
Bolt Hole Spacing 2 1/2 in
Housing Height 3 3/8 in
End Type Open End
Bearing Insert GYA012RRB
Housing No. T-40126
Bolt Hole Size 0.4219 in
Housing Length 3 3/8 in
Bolt Circle Dia. N/A
Length Through Bore 1.0625 in
Style 4-Bolt Flange
Locking Device Setscrew Locking Collar
Series SCJ
Bearing Type Ball Bearing
Flange Thickness 7/16 in
Seal Type Contact Seals
Housing Construction One Piece
Lubrication Relubricatable
Dynamic Load Rating 3200 lbf
Housing Width 3/4 in
Weight 1.128 LB
EAN or UPC 87796056824
