AMI Bearings Inc.
KHLP206-20
Narrow Inner Ring Cast Iron Housing Material Pillow Block
Item #101498666
AMI Bearings Inc.
UCLP206-20
Wide Inner Ring Cast Iron Housing Material Pillow Block
Item #101759280
- 1.25" Shaft, 1.5625" Base to Center, Contact Seals, Setscrew Locking, Non-Expansion Type
description
- Created to handle stringent food handling requirements and serve in highly corrosive applications. All assembly components have been carefully selected to comply with all applicable federal food processing requirements without compromising bearing performance needs. These units are dimensionally stable under load and can operate in continuous temperatures up to 250 °F (brief exposure up to 350 °F).The finish will not scrape or flake off during use.
applications
- Agriculture
- Fans and blowers
- Food processing
- Conveyors
| Bearing Design | Non-Expansion |
| Bearing Type | Ball Bearing |
| Bolt Hole Spacing Range [Max] | 5 9/16 in |
| Overall Width | 1 21/32 in |
| Locking Device | Setscrew Locking Collar |
| Inch/Metric | Inch Bore |
| Series | YAK Series |
| Housing Material | Cast Iron |
| Base Width | 1 9/16 in |
| Housing Height | 3 5/32 in |
| Seal Type | Contact Seals |
| Bolt Hole Spacing | 4 5/8 in |
| Bolt Size | 1/2 in |
| Base Length | 6 3/16 in |
| End Type | Open End |
| Bolt Hole Spacing Range [Min] | 3 11/16 in |
| Bearing Insert | GY1103KRRB3 |
| Length Through Bore | 1.5 in |
| Insert Type | Steel Insert |
| Base Height | 17/32 in |
| Pillow Block Type | Thru-Bolt |
| Mounted Unit Duty | Normal-Duty |
| Shaft Dia. | 1.25 in |
| Housing Construction | 1 Piece |
| Collar O.D. | 1.587 in |
| Lubrication | Relubricatable |
| Bolt Holes | 2 |
| Weight | 2.326 LB |
| EAN or UPC | 87796157507 |
