- 2.6875" Shaft, 3.5" Base to Center, Contact Seals, Setscrew Locking, Non-Expansion Type
description
- The Fafnir YASM medium-duty pillow blocks feature Fafnir's GYM-KRRB bearing inserts. These pillow blocks are ideal for conveyor, fan and blower, sawmill, and feed and grain handling applications. The durable, cast iron housings are powder paint coated, and maintain an excellent finish while resisting corrosion, chemical and weather exposure. Fafnir's industrial-duty pillow blocks incorporate premium features designed to extend bearing life and will replace competitive designs.
applications
- Agriculture
- Fans and blowers
- Food processing
- Conveyors
| Lubrication | Relubricatable |
| Insert Type | Steel Insert |
| Seal Type | Contact Seals |
| Shaft Dia. | 2.6875 in |
| Base Height | 1 1/4 in |
| Housing Height | 7 in |
| Bolt Holes | 2 |
| Length Through Bore | 3.6875 in |
| Mounted Unit Duty | Medium-Duty |
| Collar O.D. | 3.618 in |
| Bearing Type | Ball Bearing |
| Base Width | 3 1/2 in |
| Bolt Hole Spacing | 9 in |
| Overall Width | 3 11/16 in |
| End Type | Open End |
| Locking Device | Setscrew Locking Collar |
| Bolt Hole Spacing Range [Max] | 11 in |
| Bearing Design | Non-Expansion |
| Bearing Insert | GYM1211KRRB |
| Housing Material | Cast Iron |
| Bolt Size | 3/4 in |
| Inch/Metric | Inch Bore |
| Pillow Block Type | Thru-Bolt |
| Base Length | 13 in |
| Series | YASM Series |
| Housing Construction | 1 Piece |
| Bolt Hole Spacing Range [Min] | 7 |
| Weight | 26.14 LB |
| EAN or UPC | 87796197688 |
