- 2.1875" Shaft, 2.75" Base to Center, Contact Seals, Setscrew Locking, Non-Expansion Type
description
- The Fafnir YASM medium-duty pillow blocks feature Fafnir's GYM-KRRB bearing inserts. These pillow blocks are ideal for conveyor, fan and blower, sawmill, and feed and grain handling applications. The durable, cast iron housings are powder paint coated, and maintain an excellent finish while resisting corrosion, chemical and weather exposure. Fafnir's industrial-duty pillow blocks incorporate premium features designed to extend bearing life and will replace competitive designs.
applications
- Agriculture
- Fans and blowers
- Food processing
- Conveyors
| Bolt Hole Spacing Range [Max] | 8 9/16 in |
| Inch/Metric | Inch Bore |
| Shaft Dia. | 2.1875 in |
| Bearing Insert | GYM1203KRRB |
| Length Through Bore | 2.5625 in |
| Overall Width | 2 3/4 in |
| Bearing Type | Ball Bearing |
| Housing Material | Cast Iron |
| Lubrication | Relubricatable |
| Pillow Block Type | Thru-Bolt |
| End Type | Open End |
| Collar O.D. | 3.011 in |
| Base Width | 2 3/8 in |
| Base Height | 15/16 in |
| Bolt Size | 5/8 in |
| Bolt Hole Spacing | 7 13/32 in |
| Bearing Design | Non-Expansion |
| Locking Device | Setscrew Locking Collar |
| Mounted Unit Duty | Medium-Duty |
| Housing Construction | 1 Piece |
| Base Length | 9.438 in |
| Housing Height | 5 15/32 in |
| Series | YASM Series |
| Bolt Holes | 2 |
| Seal Type | Contact Seals |
| Insert Type | Steel Insert |
| Weight | 10.288 LB |
| EAN or UPC | 87796189539 |
