- B Gear Style
- 14.5° Pressure Angle
- 24 Teeth
- 24 Diametral Pitch
- 0.9999 in Pitch Diameter
description
- Martin Stock Spur Gears are available in five different styles. Contact your local Applied® service center for other styles. Steel gears are furnished in plain style and plain style with hub. Cast gears are furnished plain with hub, web with lightening holes and with spoke. Cast gears are cast with larger hub to provide extra strength and to allow for larger bores.
features
- More cost effective, quieter running and metallic options
- Four ball wear test 40 kg: 63 mm
- Reliability from steel, cast iron and brass
- Parallel shaft applications
- Base oil viscosity: 500 SUS @ 100 °F
| Hub Projection | 0.375 in |
| No. of Teeth | 24 |
| Torque at 600 RPM | 24.78983 lb/in |
| Diametral Pitch | 24 |
| Pressure Angle | 14 1/2 degrees |
| Bore Size [Min] | 0.375 in |
| Face Width | 0.25 in |
| Style | Hub |
| Keyway | w/o Keyway |
| Hardened Teeth | Without Hardened Teeth |
| Pitch Diameter | 1 in |
| Set Screw | No |
| Torque at 300 RPM | 27.731 lb/in |
| Torque at 200 RPM | 28.67637 lb/in |
| Material | Steel |
| Hub O.D. | 0.875 in |
| Torque at 900 RPM | 22.47892 lb/in |
| AGMA Quality | 6 |
| Gear Style | B |
| Outside Dia. | 1.08 in |
| Finished Bore Size | 0.375 in |
| Inch/Metric | Inch |
| Outside Dia. [Min] | 1.08 in |
| Set Screw Size | N/A |
| Origin | Reborable |
| Length Through Bore | 0.625 in |
| Material External Use | Steel |
| Hub Dia. | 7/8 in |
| Bore Type | Finished Bore |
| Torque at 1800 RPM | N/A |
| Bore Size | 0.375 in |
| O.D. | 1.083 in |
| Hub Style | B |
| Class | 6 |
| Pitch Dia. | 1 in |
| Material Internal Use | Carbon Steel |
| Type | B |
| Bore Size [Max] | 0.625 in |
| Pitch Diameter [Min] | 0.9999 in |
| Bore Dia. [Min] | 3/8 in |
| Torque at 1200 RPM | 20.53565 lb/in |
| Bore Dia. [Max] | 3/8 in |
| Weight | 0.14 LB |
| EAN or UPC | 697950058597 |
